| Model | Full Duplex/Throughput | Type | Description | Interface |
| TaskQoS N100 Series |
| N100 | B010M/T020Mbps | 1U | TaskQoS N100, up to 020Mbps | *10/100/1000 Base-T 2/4
**(bypass included) |
| N100 | B050M/T100Mbps | 1U | TaskQoS N100, up to 100Mbps |
| N100 | B100M/T200Mbps | 1U | TaskQoS N100, up to 200Mbps |
| TaskQoS N200 Series |
| N200 | B100M/T200Mbps | 2U | TaskQoS N200, up to 200Mbps | *10/100/1000 Base-T 2/4/6/8
*Fiber GigaE SX 2/4/6/8
*Fiber GigaE LX 2/4/6/8
**(bypass included) |
| N200 | B200M/T400Mbps | 2U | TaskQoS N200, up to 400Mbps |
| N200 | B600M/T1200Mbps | 2U | TaskQoS N200, up to 1200Mbps |
| N200 | B1G/T2Gbps | 2U | TaskQoS N200, up to 2Gbps |
| N200 | B2G/T4Gbps | 2U | TaskQoS N200, up to 4Gbps |
| TaskQoS N250 Series |
| N250 | B1G/T2Gbps | 2U/3.5U | TaskQoS N250, up to 2Gbps | *Fiber GigaE SX 2/4/6/8
*Fiber GigaE LX 2/4/6/8
*Fiber 10GigaE SR 2/4/8
*Fiber 10GigaE LR 2/4/8
**(bypass included) |
| N250 | B2G/T4Gbps | 2U/3.5U | TaskQoS N250, up to 4Gbps |
| N250 | B4G/T8Gbps | 2U/3.5U | TaskQoS N250, up to 8Gbps |
| N250 | B10G/T20Gbps | 2U/3.5U | TaskQoS N250, up to 20Gbps |
| TaskQoS N500 Series |
| N500 | B10G/T20Gbps | 3U | TaskQoS N500, up to 20Gbps | *Fiber bypass 10GE SR 2/4
*Fiber bypass 10GE LR 2/4
**(bypass included) |
| N500 | B20G/T40Gbps | 3U | TaskQoS N500, up to 40Gbps |
| N500 | B40G/T80Gbps | 3U | TaskQoS N500, up to 80Gbps |
| TaskQoS N1000 Series |
| N1000 | B10G/T20Gbps | 3U | TaskQoS N1000, up to 20Gbps | *Fiber 10GE SR 2/4/8/16
*Fiber 10GE LR 2/4/8/16
**(bypass included) |
| N1000 | B20G/T40Gbps | 3U | TaskQoS N1000, up to 40Gbps |
| N1000 | B40G/T80Gbps | 3U | TaskQoS N1000, up to 80Gbps |
| TaskQoS NP300 Series |
| NP300 |
B10G/T20Gbps |
2U |
TaskQoS NP300, up to 20Gbps |
*Fiber 10GE SR 2/4/8
*Fiber 10GE LR 2/4/8
**(bypass included or
External in SFP+) |
| NP300 | B20G/T40Gbps | 2U | TaskQoS NP300, up to 40Gbps |
| TaskQoS NP500 Series |
| NP500 |
B10G/T20Gbps |
3U |
TaskQoS NP500, up to 20Gbps |
*Fiber 10GE SR 2/4/8/16
*Fiber 10GE LR 2/4/8/16
*Fiber 40GE SR 2/4
*Fiber 40GE LR 2/4
**(bypass included or
External in SFP+, QSFP+) |
| NP500 | B20G/T40Gbps | 3U | TaskQoS NP500, up to 40Gbps |
| NP500 | B40G/T80Gbps | 3U | TaskQoS NP500, up to 80Gbps |
| TaskQoS NP1000 Series |
| NP1000 |
B10G/T20Gbps |
3U |
TaskQoS NP1000, up to 20Gbps |
*Fiber 10GE SR 2/4/8/16
*Fiber 10GE LR 2/4/8/16
*Fiber 40GE SR 2/4
*Fiber 40GE LR 2/4
**(bypass included or
External in SFP+, QSFP+) |
| NP1000 | B20G/T40Gbps | 3U | TaskQoS NP1000, up to 40Gbps |
| NP1000 | B40G/T80Gbps | 3U | TaskQoS NP1000, up to 80Gbps |
| NP1000 | B80G/T160Gbps | 3U | TaskQoS NP1000, up to 160Gbps |
| TaskQoS Central Management System |
| TQ-CMS | N/A | 1U | Central Policy Management & Monitoring | *10/100/1000 Base-T 2/4 |
| TQ-CMS PLUS | N/A | 2U | TQ-CMS + Log Back Up & Integrated Analysis |
